Part # |
Description |
Qty |
| 1 |
30450 |
OSBURN DOOR LOGO |
1 |
| 2 |
AC07867 |
1/2 " CHROME PLATED COIL HANDLE |
1 |
| 3 |
AC07900 |
DOOR HANDLE AND LATCH KIT |
1 |
| 4 |
SE24076 |
OSBURN 2300 CAST IRON DOOR ASSEMBLY |
1 |
| 5 |
SE30082 |
OSBURN 2300 REMPLACEMENT GLASS PL30206 |
1 |
| 5 |
AC06400 |
BLACK SELF-ADHESIVE GLASS GASKET KIT (6') |
1 |
| 6 |
AC06100 |
BLACK GASKET AND SILICONE KIT 1/4'' X 1/2'' X 6' |
1 |
| 7 |
PL39060-01 |
COLUMN BRASS TRIM BRUSH NICKEL |
2 |
| 8 |
PL30163 |
RIGHT SIDE DECORATIVE PANEL |
1 |
| 9 |
29005 |
6" X 8 1/4" X 1 1/4'' REFRACTORY BRICK HD |
2 |
| 10 |
PL30164 |
LEFT SIDE DECORATIVE PANEL |
1 |
| 11 |
PL36054 |
4" X 9" X 2 1/16" X 4 3/4'' REFRACTORY BRICK |
2 |
| 12 |
PL09524 |
BRICK RETAINER |
2 |
| 13 |
29011 |
4'' X 9" X 1 1/4" REFRACTORY BRICK HD |
21 |
| 14 |
PL36022 |
4" X 5 1/4" X 1 1/4" REFRACTORY BRICK |
1 |
| 15 |
99999 |
BUILD TO ORDER |
1 |
| 16 |
SE35047 |
ASH DRAWER |
1 |
| 17 |
VP00055 |
"NICKEL DRAWER HANDLE 4""" |
1 |
| 17 |
28061 |
CHROME ASH DRAWER HANDLE |
1 |
| 17 |
30124 |
SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC |
2 |
| 18 |
SE30028 |
AIR CONTROL DAMPER |
1 |
| 19 |
PL30207 |
GLASS RETAINER |
4 |
| 20 |
SE16059 |
ASH DUMP PLUG |
1 |
| 21 |
44080 |
RHEOSTAT WITH NUT |
1 |
| 22 |
44073 |
CROSSFLOW BLOWER 115V-60Hz-39W 100 CFM (P) |
1 |
| 22 |
44086 |
BLOWER 240V |
1 |
| 23 |
AC07865 |
1/4 "COIL HANDLE (CHROME PLATED) |
1 |
| 24 |
44085 |
RHEOSTAT KNOB |
1 |
| 25 |
SE30250 |
|
2 |
| 26 |
PL30257 |
PROTECTION WASHER |
2 |
| 27 |
21120 |
INSULATING WASHER |
2 |
| 28 |
PL52683 |
POIGNÉE AMOVIBLE |
1 |
| 29 |
30537 |
BY-PASS ROD |
1 |
| 30 |
SE45131 |
|
1 |
| 31 |
30170 |
HINGE PIN 5/16" DIA X 1 1/2" LONG |
2 |
| 32 |
AC09185 |
DOOR LATCH KIT |
1 |
