Part # |
Description |
Qty |
| 1 |
OA10040 |
BLACK DOOR OVERLAY FOR 1800-BRITANNIA |
1 |
| 1 |
OA10045 |
GOLD DOOR OVERLAY FOR 1800-BRITANNIA |
1 |
| 1 |
OA10050 |
BRUSHED NICKEL DOOR OVERLAY 1800-BRITANNIA |
1 |
| 3 |
SE43058 |
REPLACEMETN SIDE GLASS WITH GASKET 11 3/8" X 5 5/8" |
2 |
| 4 |
PL43064 |
GLASS RETAINER |
1 |
| 6 |
PL43020 |
BASE |
1 |
| 7 |
SE35021 |
HINGE ASSEMBLY |
2 |
| 8 |
SE43057 |
REPLACEMTN GLASS WITH GASKET 11 3/8" X 14 3/4" |
1 |
| 9 |
30457 |
SINGLE MAGNET |
2 |
| 10 |
PL43010 |
PEDESTAL RH SIDE |
1 |
| 11 |
PL43009 |
|
2 |
| 12 |
SE43063 |
DOOR LATCH ASSEMBLY |
2 |
| 13 |
30013 |
HINGE 2'' X 1-1/2'' |
4 |
| 14 |
PL43025 |
DECORATIVE OUTER RIGHT SIDE PANEL |
1 |
| 15 |
PL43015 |
|
2 |
| 16 |
30454 |
DOUBLE MAGNET |
4 |
| 17 |
PL43013 |
REAR PANEL |
1 |
| 18 |
OA10060 |
TOP OR REAR VENTING KIT WITH BLACK TRIM AND TRIVET |
1 |
| 18 |
OA10061 |
TOP OR REAR VENTING KIT WITH GOLD TRIM AND TRIVET |
1 |
| 18 |
OA10062 |
TOP OR REAR VENTING KIT WITH BRUSH NICKEL TRIM AND RIVET |
1 |
| 19 |
44070 |
CROSSFLOW BLOWER 115V-60Hz-56W (B) |
1 |
| 20 |
PL43035 |
|
1 |
| 21 |
PL43067 |
40% OUTLET RESTRICTOR PLATE |
1 |
| 21 |
PL43068 |
50% OUTLET RESTRICTOR PLATE |
1 |
| 21 |
PL43069 |
60% OUTLET RESTRICTOR PLATE |
1 |
| 21 |
PL43070 |
70% OUTLET RESTRICTOR PLATE |
1 |
| 21 |
PL43071 |
80% OUTLET RESTRICTOR PLATE |
1 |
| 22 |
SE43002 |
STOVE TOP |
1 |
| 23 |
PL43031 |
|
1 |
| 24 |
99999 |
BUILD TO ORDER |
1 |
| 25 |
99999 |
BUILD TO ORDER |
1 |
| 26 |
99999 |
BUILD TO ORDER |
1 |
| 27 |
99999 |
BUILD TO ORDER |
1 |
| 28 |
99999 |
BUILD TO ORDER |
1 |
| 29 |
99999 |
BUILD TO ORDER |
1 |
| 30 |
99999 |
BUILD TO ORDER |
1 |
| 31 |
PL43045 |
PULSATION DOOR SUPPORT |
1 |
| 32 |
PL43049 |
PULSATION DOOR |
1 |
| 33 |
21018 |
|
1 |
| 34 |
PL43008 |
BAFFLE |
1 |
| 35 |
PL43014 |
DECORATIVE OUTER LEFT SIDE PANEL |
1 |
| 36 |
49010 |
DIRECT VENT 45 DEGREE STARTER |
1 |
| 37 |
21017 |
FLUE ADAPTER GASKET |
1 |
| 38 |
PL43036 |
PEDESTAL LH SIDE |
1 |
| 39 |
SE43011 |
CONTROL PANEL DOOR |
1 |
| 40 |
44080 |
RHEOSTAT WITH NUT |
1 |
| 41 |
PL43011 |
|
1 |
| 42 |
28062 |
BLACK DRAWER HANDLE 3 25/32" |
1 |
| 42 |
30108 |
MECHANICAL SCREW M4 X 8MM PAN PHILLIPS ZINC |
2 |
| 43 |
PL43037 |
DECORATIVE ASH LIP |
1 |
| 44 |
SE43027 |
BURNER ASSY |
1 |
| 45 |
49199 |
HONEYWELL PILOT ASSEMBLY |
1 |
| 46 |
PL43061 |
PILOT DEFLECTOR |
1 |
| 47 |
21005 |
PILOT GASKET IN 1/8 CERAMIC PAPER |
2 |
| 48 |
PL43043 |
PILOT STAND OFF |
1 |
| 49 |
44046 |
THERMODISC F110-20F |
1 |
| 50 |
44093 |
ROCKER SWITCH 2 POSITION (ON - OFF) WITH GOLD CONTACT |
1 |
| 51 |
44085 |
RHEOSTAT KNOB |
1 |
| 52 |
PL43030 |
CONTROL PANEL |
1 |
| 53 |
49052 |
VALVE HONEYWELL WESTBAY (HG93) |
1 |
| 54 |
SE43007 |
BURNER TRAY BRITANNIA 31 |
1 |
| 55 |
SE43016 |
AIR SHUTTER ASSY |
1 |
| 56 |
9071-0 |
# 36 NATURAL INTAKE BURNER (ORIFICE) |
1 |
| 56 |
9071-01 |
PROPANE # 52 INTAKE BURNER (ORIFICE) |
1 |
