Part # |
Description |
Qty |
| 1 |
OA10230 |
BLACK CAST IRON DOOR OVERLAY 1600 |
1 |
| 1 |
OA10231 |
BROWN CAST IRON DOOR OVERLAY 1600 |
1 |
| 1 |
OA10232 |
GOLD PLATED CAST IRON DOOR OVERLAY1600 |
1 |
| 1 |
OA10234 |
BRUSHED NICKEL CAST IRON DOOR OVERLAY 1600 |
1 |
| 2 |
30123 |
SCREW #8 - 32 X 5/8'' PAN QUADREX ZINC |
4 |
| 3 |
30450 |
OSBURN DOOR LOGO |
1 |
| 4 |
30124 |
SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC |
7 |
| 5 |
AC07868 |
1/2 " BLACK COIL HANDLE |
1 |
| 6 |
SE24164 |
OSBURN 1000, 1100, 1600 CAST IRON DOOR WITH HANDLE |
1 |
| 7 |
AC09187 |
HANDLE AND LATCH KIT |
1 |
| 8 |
AC09185 |
DOOR LATCH KIT |
1 |
| 9 |
30101 |
SPRING TENSION PIN 5/32" DIA X 1 1/2" LONG |
1 |
| 10 |
SE34103 |
REPLACEMENT GLASS WITH GASKET 10 1/8" X 16 1/8" |
1 |
| 11 |
AC06400 |
BLACK SELF-ADHESIVE GLASS GASKET KIT (6') |
1 |
| 12 |
SE34060 |
GLASS RETAINER FRAME WITH GASKET 1000-1100-1600 SERIE |
1 |
| 13 |
OA11395 |
SILICONE AND GASKET REPLACEMENT KIT 1/2" x 8' |
1 |
| 14 |
PL34033-01 |
LEFT DECORATIVE PANEL 1600 STOVE |
1 |
| 15 |
30341 |
PIN 5/16" x 1 1/2" |
2 |
| 16 |
PL34039 |
BRASS DECORATIVE COLOMN 1600 STOVE |
2 |
| 16 |
PL34039-01 |
NICKEL DECORATIVE COLUMN 1600 STOVE |
2 |
| 16 |
PL34039-02 |
BLACK DECORATIVE COLUMN 1600 STOVE |
2 |
| 17 |
PL34027 |
AIR CONTROL COVER |
1 |
| 18 |
AC07866 |
1/4 " BLACK COIL HANDLE |
1 |
| 19 |
SE34024 |
AIR CONTROL ROD ASSEMBLY |
1 |
| 20 |
30063 |
1/4" ID PUSHNUT |
1 |
| 21 |
SE34021 |
AIR CONTROL PLATE |
1 |
| 22 |
PL34033 |
RIGHT DECORATIVE PANEL 1600 STOVE |
1 |
| 23 |
99999 |
BUILD TO ORDER |
1 |
| 24 |
OA10200 |
CAST IRON BLACK LEG KIT WITH ASH PAN 1600-6L001 |
1 |
| 24 |
OA10205 |
CAST IRON GOLD PLATED LEG KIT WITH ASH PAN 1600-6L002 |
1 |
| 24 |
OA10207 |
BRUSHED NICKEL LEG KIT WITH ASH PAN 1600 |
1 |
| 25 |
PL34009 |
LEFT LEGS AND DRAWER SUPPORT |
1 |
| 26 |
PL34010 |
LEGS AND DRAWER RIGHT MOUNTING SUPPORT |
1 |
| 27 |
SE34037 |
ASH DRAWER FOR OSBURN 1600 ON LEGS |
1 |
| 28 |
24023 |
BLACK CAST IRON LEG WITH LEVELING BOLT |
4 |
| 28 |
PL24023-01 |
GOLD PLATED CAST IRON LEG WITH LEVELING BOLT |
4 |
| 28 |
PL24023-02 |
NICKEL PLATED CAST IRON LEG WITH LEVELING BOLT |
4 |
| 29 |
30050 |
LEVELING BOLT 3/8-16 X 1 1/2" |
4 |
| 30 |
OA10215 |
PEDESTAL WITH ASH PAN 1600 |
1 |
| 31 |
SE34044 |
ASH DRAWER 1600 (PEDESTAL) |
1 |
| 32 |
30418 |
FINISHING PLUG 3/8" |
2 |
| 33 |
SE16059 |
ASH DUMP PLUG |
1 |
| 34 |
29020 |
4 1/2'' X 9'' X 1 1/4'' REFRACTORY BRICK HD |
5 |
| 35 |
PL36046 |
4" 1/2 X 9" X 1" X 1" REFRACTORY BRICK |
2 |
| 36 |
PL36021 |
REFRACTORY BRICK 2 1/8" X 9" X 1 1/4'' |
4 |
| 37 |
PL36049 |
4 1/2" X 4 1/2'' X 1 1/4'' REFRACTORY BRICK |
1 |
| 38 |
PL36024 |
1 7/8" X 4 1/2" X 1 1/4" REFRACTORY BRICK |
2 |
| 39 |
PL36055 |
4 1/2" X 9" X 7/8" X 5'' REFRACTORY BRICK |
2 |
| 40 |
29016 |
4 1/2" x 9" x 2 1/2" REFRACTORY BRICK HD |
4 |
| 41 |
PL34019 |
FRONT SECONDARY AIR TUBE |
1 |
| 42 |
30068 |
STAINLESS STEEL COTTER PIN 1/8" X 1 1/2" |
1 |
| 43 |
21291 |
C-CAST BAFFLE 13 1/2" X 10" X 1 1/4" |
2 |
| 44 |
PL34047 |
10 1/2" x 13 1/2" x 1" BAFFLE INSULATION |
2 |
| 45 |
PL34026 |
BAFFLE INSULATION WEIGHT |
2 |
| 46 |
SE45022 |
OSBURN 1600 STOVE INSTRUCTION MANUEL KIT |
1 |
