Part # |
Description |
Qty |
| 1 |
AC07868 |
1/2 " BLACK COIL HANDLE |
1 |
| 2 |
30112 |
SPRING PIN 5/16" x 1 3/8" |
1 |
| 3 |
SE37150 |
DOOR ASSEMBLY WITHOUT OVERLAY 1800 SERIE |
1 |
| 4 |
AC26005 |
DOOR HANDLE AND LATCH KIT 1800-2200 SERIE |
1 |
| 5 |
AC09185 |
DOOR LATCH KIT |
1 |
| 6 |
SE37154 |
5 3/8'' X 10 13/16" REPLACEMENT GLASS WITH GASKET |
2 |
| 7 |
AC06400 |
BLACK SELF-ADHESIVE GLASS GASKET KIT (6') |
3 |
| 8 |
SE37155 |
REMPLACEMENT GLASS WITH GASKET 14 3/4'' X 10 13/16'' |
1 |
| 9 |
PL37151 |
RIGHT OR LEFT GLASS RETAINER |
2 |
| 10 |
PL37134 |
"FACEPLATE RIGHT SIDE 32"" X 44""" |
2 |
| 11 |
30026 |
THREAD CUTTING SCREW 10-24 F 5/8" HEX WASHER HEAD |
12 |
| 12 |
OA11390 |
SILICONE & DOOR GASKET REPLACEMENT KIT 7/8" (8 FEET) |
1 |
| 13 |
28062 |
BLACK DRAWER HANDLE 3 25/32" |
1 |
| 14 |
30108 |
MECHANICAL SCREW M4 X 8MM PAN PHILLIPS ZINC |
2 |
| 15 |
SE37037 |
1800 PEDESTAL ASH DRAWER |
1 |
| 16 |
99999 |
BUILD TO ORDER |
1 |
| 17 |
30418 |
FINISHING PLUG 3/8" |
2 |
| 18 |
SE45059 |
INSTRUCTION MANUAL OSBURN 1800 STOVE |
1 |
| 19 |
PL37018 |
RIGHT DECORATIVE PANEL 1800 STOVE |
1 |
| 20 |
99999 |
BUILD TO ORDER |
1 |
| 21 |
PL37025 |
ASH SHELF 1800 STOVE |
1 |
| 22 |
PL35056 |
SHIM |
1 |
| 23 |
SE35021 |
HINGE ASSEMBLY |
2 |
| 24 |
PL37019 |
LEFT DECORATIVE PANEL 1800 STOVE |
1 |
| 25 |
AC07866 |
1/4 " BLACK COIL HANDLE |
1 |
| 26 |
PL37029 |
AIR CONTROL COVER 1800 STOVE |
1 |
| 27 |
SE34024 |
AIR CONTROL ROD ASSEMBLY |
1 |
| 28 |
30063 |
1/4" ID PUSHNUT |
2 |
| 29 |
SE37035 |
AIR CONTROL PLATE 1800 STOVE |
1 |
| 30 |
SE16059 |
ASH DUMP PLUG |
1 |
| 31 |
29001 |
4'' X 8'' X 1 1/4'' REFRATORY BRICK HD |
6 |
| 32 |
29011 |
4'' X 9" X 1 1/4" REFRACTORY BRICK HD |
3 |
| 33 |
VP00016 |
3 1/2'' X 4'' X 1 1/4'' REFRACTORY BRICK |
1 |
| 34 |
PL36027 |
3" X 9" X 1 1/4'' REFRACTORY BRICK |
2 |
| 35 |
PL37031 |
FRONT SECONDARY AIR TUBE 1800 SERIE |
1 |
| 36 |
PL37030 |
REAR AND MIDDLE SECONDARY AIR TUBE 1800 SERIE |
2 |
| 37 |
30068 |
STAINLESS STEEL COTTER PIN 1/8" X 1 1/2" |
3 |
| 38 |
21295 |
C-CAST BAFFLE 10 7/8" X 9 7/16" X 1 1/4" |
2 |
| 39 |
PL37027 |
11" X 9 5/8" X 1/2" RIGID BAFFLE INSULATION |
2 |
