Part # |
Description |
Qty |
| 1 |
OA10220 |
BLACK CAST IRON DOOR OVERLAY 2000 |
1 |
| 1 |
OA10221 |
BROWN CAST IRON DOOR OVERLAY 2000 |
1 |
| 1 |
OA10222 |
GOLD PLATED CAST IRON DOOR OVERLAY 2000 |
1 |
| 1 |
OA10224 |
BRUSHED NICKEL CAST IRON DOOR OVERLAY 2000 |
1 |
| 2 |
30123 |
SCREW #8 - 32 X 5/8'' PAN QUADREX ZINC |
4 |
| 3 |
30450 |
OSBURN DOOR LOGO |
1 |
| 4 |
30124 |
SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC |
1 |
| 5 |
AC07868 |
1/2 " BLACK COIL HANDLE |
1 |
| 6 |
SE53595 |
CAST IRON DOOR WITH HANDLE AND GASKET OSBURN 2000 |
1 |
| 7 |
AC07900 |
DOOR HANDLE AND LATCH KIT |
1 |
| 8 |
AC09185 |
DOOR LATCH KIT |
1 |
| 9 |
AC06000 |
SILICONE AND 1/2" x 8' BLACK GASKET REPLACEMENT KIT (DOOR) |
1 |
| 10 |
30101 |
SPRING TENSION PIN 5/32" DIA X 1 1/2" LONG |
1 |
| 11 |
SE53597 |
REPLACEMENT GLASS WITH GASKET 10 9/16" X 18" |
1 |
| 12 |
AC06400 |
BLACK SELF-ADHESIVE GLASS GASKET KIT (6') |
1 |
| 13 |
PL53588 |
GLASS RETAINER FRAME |
2 |
| 14 |
PL53585 |
GLASS RETAINER |
8 |
| 15 |
30124 |
SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC |
8 |
| 16 |
PL53644 |
ASH SHELF |
1 |
| 17 |
SE53645 |
BLOWER ASSEMBLY WITH HOUSING OSBURN 2000 INSERT |
1 |
| 18 |
60013 |
POWER CORD 96" X 18-3 |
1 |
| 19 |
44089 |
DOUBLE CAGE BLOWER 120CFM 115V |
1 |
| 20 |
44087 |
RHEOSTAT NUT |
1 |
| 21 |
44080 |
RHEOSTAT WITH NUT |
1 |
| 22 |
44046 |
THERMODISC F110-20F |
1 |
| 23 |
44085 |
RHEOSTAT KNOB |
1 |
| 24 |
SE53529 |
AIR CONTROL DAMPER WITH HARDWARE |
1 |
| 25 |
30206 |
ZINC WASHER ID=5/16" x OD=3/4" |
1 |
| 26 |
30060 |
THREAD-CUTTING SCREW 1/4-20 x 1/2" F HEX STEEL SLOT WASHER C102 ZINC |
1 |
| 27 |
PL53616 |
AIR CONTROL ROD |
1 |
| 28 |
AC07866 |
1/4 " BLACK COIL HANDLE |
1 |
| 29 |
SE45450 |
INTRUCTION MANUAL KIT OSBURN 2000 INSERT |
1 |
| 30 |
PL53642 |
RIGHT DECORATIVE PANEL OSBURN 2000 INSERT |
1 |
| 31 |
PL53643 |
LEFT DECORATIVE PANEL OSBURN 2000 INSERT |
1 |
| 32 |
PL53869 |
FACEPLATE EXTENSION |
1 |
| 33 |
29020 |
4 1/2'' X 9'' X 1 1/4'' REFRACTORY BRICK HD |
12 |
| 34 |
PL36049 |
4 1/2" X 4 1/2'' X 1 1/4'' REFRACTORY BRICK |
1 |
| 35 |
29011 |
4'' X 9" X 1 1/4" REFRACTORY BRICK HD |
1 |
| 36 |
29001 |
4'' X 8'' X 1 1/4'' REFRATORY BRICK HD |
4 |
| 37 |
PL36047 |
4 1/2" X 6 1/2" X 1 1/4" REFRACTORY BRICK |
3 |
| 38 |
PL53533 |
FRONT BAFFLE SUPPORT |
1 |
| 39 |
30068 |
STAINLESS STEEL COTTER PIN 1/8" X 1 1/2" |
3 |
| 40 |
PL53516 |
FRONT SECONDARY AIR TUBE |
1 |
| 41 |
PL53517 |
REAR OR MIDDLE SECONDARY AIR TUBE |
2 |
| 42 |
21293 |
C-CAST BAFFLE 20 1/2" X 13 1/4" X 1 1/4" |
1 |
| 43 |
21013 |
13 1/2'' X 23 1/2'' X 1/2'' BAFFLE INSULATION |
1 |
| 44 |
PL34026 |
BAFFLE INSULATION WEIGHT |
1 |
| 45 |
OA10121 |
BRASS REGULAR FACEPLATE TRIM KIT (29" X 44") |
1 |
| 45 |
OA10122 |
BLACK REGULAR FACEPLATE TRIM KIT (29" X 44") |
1 |
| 45 |
OA10123 |
BRUSHED NICKEL FACEPLATE TRIM KIT (29" X 44") |
1 |
| 45 |
OA10127 |
BRASS LARGE FACEPLATE TRIM KIT (32" X 50") |
1 |
| 45 |
OA10128 |
BLACK LARGE FACEPLATE TRIM KIT (32" X 50") |
1 |
| 45 |
OA10129 |
BRUSHED NICKEL FACEPLATE TRIM KIT (32" X 50") |
1 |
| 46 |
SE15097 |
FACEPLATE HARDWARE KIT |
1 |
| 47 |
AC03410 |
REGULAR FACEPLATE 29" X 44" |
1 |
| 47 |
AC03411 |
LARGE FACEPLATE 32" X 50" |
1 |
