Part # |
Description |
Qty |
| 1 |
30450 |
OSBURN DOOR LOGO |
1 |
| 2 |
30124 |
SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC |
9 |
| 3 |
AC07868 |
1/2 " BLACK COIL HANDLE |
1 |
| 4 |
SE24220 |
DOOR ASSEMBLY |
1 |
| 5 |
AC06200 |
BLACK GASKET AND SILICONE KIT 1/4'' X 1/2'' X11' |
1 |
| 6 |
AC07900 |
DOOR HANDLE AND LATCH KIT |
1 |
| 7 |
AC09185 |
DOOR LATCH KIT |
1 |
| 8 |
30101 |
SPRING TENSION PIN 5/32" DIA X 1 1/2" LONG |
1 |
| 9 |
SE63190 |
REPLACEMENT GLASS WITH GASKET 8 3/4" x 14" |
1 |
| 10 |
AC06400 |
BLACK SELF-ADHESIVE GLASS GASKET KIT (6') |
1 |
| 11 |
PL63184 |
GLASS RETAINER FRAME |
2 |
| 12 |
PL53585 |
GLASS RETAINER |
8 |
| 13 |
PL34036 |
ASH SHELF |
1 |
| 14 |
PL63185 |
UNDERSIDE HEAT SHIELD |
1 |
| 15 |
24023 |
BLACK CAST IRON LEG WITH LEVELING BOLT |
4 |
| 16 |
30050 |
LEVELING BOLT 3/8-16 X 1 1/2" |
4 |
| 17 |
99999 |
BUILD TO ORDER |
1 |
| 18 |
SE45449 |
OSBURN 900 INSTRUCTION MANUAL KIT |
1 |
| 19 |
AC07866 |
1/4 " BLACK COIL HANDLE |
1 |
| 20 |
30125 |
MECHANICAL SCREW #8 X 1 1/4" QUADREX ZINC |
2 |
| 21 |
PL63186 |
AIR CONTROL COVER |
1 |
| 22 |
30094 |
HEX SCREW WASHER HEAD 1/4-20 X 3/4" F ZINC TYPE |
2 |
| 23 |
30428 |
BUSHING |
2 |
| 24 |
SE63017 |
AIR CONTROL DAMPER |
1 |
| 25 |
29011 |
4'' X 9" X 1 1/4" REFRACTORY BRICK HD |
4 |
| 26 |
29020 |
4 1/2'' X 9'' X 1 1/4'' REFRACTORY BRICK HD |
10 |
| 27 |
PL36027 |
3" X 9" X 1 1/4'' REFRACTORY BRICK |
2 |
| 28 |
PL36046 |
4" 1/2 X 9" X 1" X 1" REFRACTORY BRICK |
2 |
